Product Overview
Build a comfortable, thoughtfully designed sauna around the Harvia KIP Series Sauna Heater - External Control. This Harvia heater combines its recognizable design with model-specific heating options; compare the available configurations and installation requirements below to choose the best fit for your sauna.
Model Comparison
| Model |
Output |
Sauna Room |
Electrical |
Breaker |
Stones |
| KIP45W |
4.5 kW |
100-210 CU. FT. |
240V / 1PH |
30A |
44 lbs (20 kg) |
| KIP45W |
4.5 kW |
100-210 CU. FT. |
208V / 3PH |
30A |
44 lbs (20 kg) |
| KIP60W |
6 kW |
170-300 CU. FT. |
240V / 1PH |
30A |
44 lbs (20 kg) |
| KIP60W |
6 kW |
170-300 CU. FT. |
208V / 3PH |
30A |
44 lbs (20 kg) |
| KIP80W |
8 kW |
250-425 CU. FT. |
240V / 1PH |
40A |
44 lbs (20 kg) |
| KIP80W |
8 kW |
250-425 CU. FT. |
208V / 3PH |
30A |
44 lbs (20 kg) |
Additional Specifications
-
Stone Type: AC3000
-
Dimensions: 16" (410mm) × 11" (280mm) × 24" (600mm)
Choosing Your Model
Select the variant that matches your sauna and electrical installation. Output, room-size range, electrical requirements, stone capacity, finish, and control compatibility can vary by model; compare the specifications above before ordering.
Installation Information
Review the model-specific Harvia installation and operation manual before purchase and installation. Electrical work must follow applicable codes and should be verified by a licensed electrician. Sauna sizing should account for glass, masonry, and other non-insulated surfaces.
Before You Order
Confirm the selected model’s heater output, sauna room suitability, control requirements and sauna stone specifications using the product details and Harvia installation manual. For wood-burning models, verify flue routing, clearances and required protective components; for electric models, have a qualified electrician confirm the electrical installation.
